Nanobubbles - gas-filled bubbles with diameters typically <1 µm - have rapidly moved from laboratory curiosities to practical tools across water treatment, agriculture, aquaculture, and biomedical fields. This article reviews the state-of-the-art generation techniques: ultrasonic cavitation, electrochemical production, and hydrodynamic methods. For each approach, a summarized physical mechanism, notable technical innovations, trade-offs in cost and energy, and how they affect nanobubble stability and usability in real-world applications. We conclude with a comparative assessment and a forward-looking view on hybrid systems and commercialization bottlenecks.

Nanobubbles differ from larger micro- and macro-bubbles primarily in size-dependent surface phenomena: very high surface-area-to-volume ratios, large internal pressure (Laplace pressure), and strong interfacial charge effects (zeta potential). Those properties give rise to enhanced mass transfer, prolonged suspension times, and unusual chemical reactivity-advantages for oxidation, flotation, pollutant removal, and oxygenation. Generating consistent, stable nanobubble populations at scale, however, remains the engineering challenge. Three methods dominate current research and industrial deployments: ultrasonic cavitation, electrochemical generation, and hydrodynamic cavitation/venturi-based techniques. Each has recently seen innovations that improve energy efficiency, control over size distribution, and bubble longevity.

Mechanism and strengths

Ultrasonic generation uses high-frequency acoustic fields to induce cavitation - formation, growth, and violent collapse of gas/vapor cavities - which produces tiny daughter bubbles and gas nuclei. The high local pressures and shear during collapse fragment bubbles down into the nanoscale. Ultrasonics offers precise tunability (frequency, power, duty cycle), and produces very small bubbles with narrow size distributions in certain regimes.

Recent innovations

• Frequency multiplexing: Using combined low (tens of kHz) and high (hundreds of kHz–MHz) frequencies reduces energy losses while promoting stable nucleation and fragmentation, improving yield of sub-200 nm bubbles.
• Pulse modulation and duty optimization: Pulsed sonication lessens thermal loading and improves cavitation control, providing higher energy efficiency per nanobubble produced.
• Through engineered horn structures and custom geometries, supported by accurately aligned probes and acoustic reflectors, stable cavitation regions are formed.
• In-situ monitoring: Non-invasive optical and acoustic diagnostics (e.g., scattering, high- speed imaging) allow closed-loop control of sonication to maintain target bubble size distributions.

Ultrasonics can be energy-intensive for high-throughput applications and may generate localized heating that harms temperature-sensitive systems. Scaling from lab to industrial volumes while keeping energy per volume low is still nontrivial.

Mechanism and strengths

Electrochemical methods create gas at electrode surfaces (e.g., H₂ or O₂) via electrolysis. Under specific electrode designs and current regimes, the nascent gas forms extremely small bubbles that detach as nanobubbles or form a population that collapses into nanobubbles through hydrodynamic shear. Electrochemical systems naturally integrate with disinfection and redox-based processes, enabling gas generation on demand without external compressors.

Recent innovations

• Micro/nanostructured electrodes: Porous, high-surface-area electrodes (e.g., carbon nanotube arrays, porous metals) create distributed nucleation sites, producing many uniformly small bubbles at lower overpotentials.
• Pulse electrolysis and bipolar pulsing: Short, high-current pulses promote the formation of numerous small nuclei while minimizing coalescence and gas film formation.
• Catalyst and coating engineering: Hydrophobic coatings and tailored surface energies encourage formation of detached nanobubbles rather than large adherent layers.
• Integrated electrochemical–hydrodynamic systems: Combining electrodes in flow channels uses shear to strip and disperse nanobubbles efficiently into bulk fluid.

Electrochemical generation requires conductive fluids or the addition of electrolytes, can produce by- products depending on electrode chemistry, and electrode fouling is a practical concern. Energy efficiency is good for on-demand low-volume generation but must be optimized for larger flows.

Mechanism and strengths

Hydrodynamic cavitation uses rapid pressure drops (venturi constrictions, orifice plates, rotor–stator systems) to create vapor/gas cavities that collapse downstream, producing nano- and micro-bubbles. These systems are mechanically simple, scale well, and integrate easily into existing piping systems.

Recent innovations

• Swirl and static swirl flow sections
• Multi-stage constrictions and gradual expansion designs
• Computational optimization
• Additive manufacturing (3D printing)

Hydrodynamic systems often require pumps and induce pressure losses; erosion and maintenance are concerns in abrasive or dirty fluids. Control over the smallest size fractions (<100 nm) is harder compared with ultrasonic or electrochemical methods.

Energy per unit gas delivered: Hydrodynamic methods typically win for large-volume, low- cost implementations (e.g., irrigation, aquaculture), because they leverage existing pump energy. Ultrasonics can be more energy intensive, especially at high throughputs, but innovations like pulsing and better focusing reduce that gap. Electrochemical approaches can be very efficient where electricity is cheap and where gas generation on-site avoids compression/storage costs.

Capital and maintenance costs: Hydrodynamic equipment is mechanically robust and low- cost; ultrasonics require capital for transducers and control systems and suffer from transducer wear; electrochemical systems require periodic electrode maintenance/replacement and may need corrosion-resistant materials.

Bubble stability: Stability depends less on generation method and more on surface chemistry (zeta potential), dissolved gas saturation, presence of surfactants, and water chemistry (ionic strength). Ultrasonics and electrochemical methods can produce very small and often more uniformly charged bubbles, which helps stability. Hydrodynamic systems benefit when downstream flow conditioning and chemical control (e.g., dissolved salts, stabilizers) are applied.

Operational flexibility:Electrochemical systems offer on-demand gas type control and coupling to redox processes; ultrasonics enable fine size control via frequency/power; hydrodynamic methods excel at retrofit and scale.

A clear trend is hybridization: combining electrochemical or ultrasonic nucleation with hydrodynamic dispersion to get the benefits of both precise nucleation and energy-efficient distribution. Other trends include real-time sensors for bubble population control, the use of surface-active additives or polymeric stabilizers to prolong bubble lifetime, and eco-design using low-energy drivers (e.g., waste heat-driven ultrasonics or variable-speed pumps).

For the formation of nanobubbles, hydrodynamic methods, electrochemical generation, and ultrasonic cavitation all have unique benefits. Advances in flow geometry, electrode microstructure, and acoustic control are bridging the gap between lab capabilities and real-world, affordable implementation. Hybrid systems that combine energy-efficient hydrodynamic dispersion with precise nucleation (either electrochemical or ultrasonic) and process controls that adjust bubble chemistry for stability in the intended application offer the most promising short-term route to commercial viability. These advancements put nanobubbles in a position to become widely used instruments in the biomedical, agricultural, and environmental domains.
