The NICO DRONA Nanobubble System enhances water treatment efficiency in oil & gas operations by improving oxidation, separation, and microbial processes through advanced gas–liquid interaction.
It seamlessly integrates with wastewater plants, produced water systems, offshore platforms, and process loops, delivering cleaner water, reduced odors, and improved overall operational performance.
Optimizing process and produced water in oil & gas with advanced
nanobubble technology.
Efficiently cleans and oxygenates produced water for safer discharge or reuse.
Boosts oxidation and contaminant removal for cleaner refinery effluents.
Enhances breakdown and stability of sludge and drilling waste.
Reduces hydrogen sulfide and associated odors for safer operations.
Prevents biofilm buildup and maintains pipeline efficiency.
Improves water quality to support advanced recovery processes.
Measurable improvements in water quality, clarity, and overall system
performance.
Improves oxygen transfer, gas–liquid interaction, hydrocarbon separation, and flotation performance.
Reduces sulfide odors, improves water quality, and lowers sludge generation.
Boosts microbial performance for treatment and enhanced oil recovery.
Supports operational stability and integrates easily with existing refinery and produced water systems.
Compare models to find the right NICO DRONA Nanobubble System for your oil & gas water treatment and process water needs.
| Models | Units | NICO DRONA 01 | NICO DRONA 05 | NICO DRONA 10 | NICO DRONA 30 | NICO DRONA 100 | |
|---|---|---|---|---|---|---|---|
| Flow Rate | m³/hr | 1.35 | 5 | 10 | 30 | 100 | |
| LPH | 1350 | 5000 | 10000 | 30000 | 100000 | ||
| System Pressure | bar | 2 | 2-3 | 2-3 | 2-3 | 2-3 | |
| Nanobubble Size | nm | 50-200 | 50-200 | 50-200 | 50-200 | 50-200 | |
| Zeta potential | mV | up to -43 mV | up to -43 mV | up to -43 mV | up to -43 mV | up to -43 mV | |
| Gas usage | Air, Oxygen, Ozone | ||||||
| Oxygen Flow Rate | LPM | 1.5 | 7 | 14 | 40 | 133 | |
| Oxygen Pressure | PSI | >7 | >7 | >7 | >7 | >14.5 | |
| Ozone Flow Rate | GPH | 3-5 | 16 | 70 | 200 | 600 | |
| Oxygen Pressure | PSI | < 1.1-1.2 | < 1.1-1.2 | < 1.1-1.2 | < 1.1-1.2 | < 1.1-1.2 | |
| Suction Line Size | inch | 1.5 | 1.5 | 2.0 | 3.0 | 4.0 | |
| Discharge Line Size | inch | 1.0 | 1.0 | 2.0 | 3.0 | 4.0 | |
*NICO DRONA 20, 50, 250, 500, 1000 systems available, with configurable specifications based on application requirements.
The system is suitable for produced water treatment, refinery wastewater, offshore platform water systems, process water loops, tank bottom water, hydraulic fracturing fluids, and more, supporting improved efficiency and compliance.
By generating ultra-fine nanobubbles, the system enhances gas-liquid interaction, oxidation, separation, and biological treatment. This leads to better hydrocarbon removal, reduced sulfide odors, improved flotation performance, and enhanced microbial processes.
Models range from NICO DRONA 01 to NICO DRONA 100, with flow rates from 1.35 – 100 m³/hr (1350–100,000 LPH). Customized models such as DRONA 20, 50, 250, 500, and 1000 are also available to suit specific process requirements.
